MORE POWER MORE RELIABLE
Module efficiency up to 21.2%
Compatible with mainstream trackers
Cost effective product for utility power plant.
Better shading tolerance.
Lower internal current,lower hot spot temperature Minimizes micro-crack impacts Heavy snow load up to 5400 Pa, wind load up to 2400 Pa.
Nominal Max. Power (Pmax) | 580W | 585W | 590W | 595W | 600W | 605W |
Opt. Operating Voltage (Vmp) | 34.1V | 34.3V | 34.5V | 34.7V | 34.9V | 35.1V |
Opt. Operating Current (Imp) | 17.02A | 17.06A | 17.11A | 17.15A | 17.20A | 17.25A |
Open Circuit Voltage (Voc) | 40.5V | 40.7V | 40.9V | 41.1V | 41.3V | 41.5V |
Short Circuit Current (Isc) | 18.27A | 18.32A | 18.37A | 18.42A | 18.47A | 18.52A |
Module Efficiency | 20.50% | 20.70% | 20.80% | 21.00% | 21.20% | 21.40% |
Operating Temperature | ~40°C ~ +85°C | |||||
Max. System Voltage | 1500V (IEC) or 1000V (IEC) | |||||
Module Fire Performance | CLASS C (IEC 61730) | |||||
Max. Series Fuse Rating | 30 A | |||||
Application Classification | Class A | |||||
Power Tolerance | 0 ~ + 10 W | |||||
Cell Type | 210mm wafer /Mono-crystalline | |||||
Cell Arrangement | 120 [2 x (10 x 6) ] | |||||
Dimensions | 2172 ˣ 1303 ˣ 35 mm (85.5 ˣ 51.3 ˣ 1.38 in) | |||||
Weight | 31.4 kg (69.2 lbs) | |||||
Front Cover | 3.2 mm tempered glass | |||||
Frame | Anodized aluminium alloy, crossbar enhanced | |||||
J-Box | IP68, 3 bypass diodes | |||||
Cable | 4 mm2 (IEC) | |||||
Per Pallet | 31 pieces | |||||
Per Container | 40HQ/527 pieces | |||||
