APP Monitor
Powerful and Reliable 5~10 Years Service Life
Environmental Friendly
Built-in Safety ProtectionIntelligent Bluetooth
BMS Support Parellels
Technical Specifications | ||||
50AH | 100AH | 120AH | 200AH | |
Nominal Voltage | 12.8 V/25.6V | Recommended Charge Current | 50 A | |
Nominal Capacity | 50 AH @ 0.2C | Max. Charge Current | 100 A | |
Energy | 1280 Wh | Max. Continuous Discharge Current | 100 A | |
Internal Resistance（AC） | 30 mΩ | Peak Discharge Current | 200 A （3S） | |
Cycle Life | 6000+ Cycles @ 1C 100% DOD | BMS Discharge Cut-off Voltage | 10 V | |
Monthly Self Discharge | Less than 2% | Charge Temperature | 0~45 ℃ | |
Efficiency of Charge | 100% @ 0.5 C | Discharge Temperature | -20℃ to 60 ℃ | |
Efficiency of Discharge | 96~99% @1 C | Storage Temperature | -20℃ to 60 ℃ | |
Charge Voltage | 14.6 ± 0.2 V | IP Class | IP65 | |
Charge Model | 0.2C to 14.6 V , then 14.6 V , charge current to 0.02C | Maximum Modules in Series/parallels | 4S or 4P | |
